Soil Density Gauge - SR4500 Murah

An Electrical Density Gauge (EDG) is a nuclear-free, portable instrument used to determine the density and moisture content of compacted soils and other construction materials. It's often used as an alternative to the traditional nuclear density gauge for field testing. The EDG works by measuring the electrical dielectric properties and moisture levels of the soil.

An Electrical Density Gauge (EDG) is a non-nuclear device used primarily in civil engineering and construction to measure the density and moisture content of compacted soils and aggregates. It offers an alternative to traditional nuclear density gauges, which use radioactive materials and require strict regulatory controls.

Soil Density Gauge - SR4500 Murah

Berikut ini adalah beberapa series dari Electrical Density Gauge / Soil Density Gauge sebagai berikut :

NOTE / CATATAN pengganti/penerus dari tipe SR-4500 adalah EDG-1S

Click Here : Soil Density Gauge (EDG) - SR4500 Brochure

Click Here : Non-Nuclear Soil Electrical Density Gauge | EDG-1S Brochure

Click Here : HUMBOLDT Electrical Density Gauge Brochure

Click Here : PT. Mora Anugerah Berkat Telah Terdaftar di E-Catalog LKPP

The EDG operates based on electrical impedance and resistivity principles. Here's a simplified breakdown :

1. Probes are inserted into the soil.

2. The EDG sends an electrical signal through the soil via the probes.

3. The device measures the resistance to electrical flow, which is influenced by :

-> Soil density

-> Soil moisture content

-> Soil type (clay, sand, gravel, etc.)

4. The EDG calculates :

-> Wet density

-> Dry density

-> Moisture content

-> Relative compaction (with reference data)

5. EDG Test Picture

The Electrical Density Gauge (EDG) is a nuclear-free alternative for determining the moisture and density of compacted soils used in road beds and foundations.

The EDG is a portable, battery-powered instrument capable of being used anywhere without the concerns and regulations associated with nuclear safety.

Its user-friendly, step-by-step menu guides the user through each step of the testing procedure and cautions the user when values do not correspond to established curves for the material being tested.

Easy-to-use, the EDG can be used as a construction aid to monitor day-to-day compaction operations by providing performance and measurement results highly comparable to those achieved with traditional methods, including the nuclear gauge and/or a sand-cone and oven moisture test combination.

When conducting a test, the EDG measures and displays the results for wet and dry density, gravimetric moisture content and percent compaction.

Soil Density Gauge - SR4500 Murah

1. EDG Console/Computer

The EDG unit contains a computer that applies mathematical formulas to determine the physical characteristics of the soil.

The computer also contains memory that remains intact after the EDG has been powered off. This memory is used to save Soil Models and Job Site data. See Appendix

A for information on EDG memory capacity. The EDG console has an LCD display which is used to provide visual information to the user and a keypad that allows the

user to key information into the EDG unit.

2. Electric Soil Measurement Sensor

The Soil Sensor gathers electrical information about the soil under test and transfers the information to the EDG computer.

3. Dart Template

4. Temperature Probe

When performing EDG Testing, the temperature probe should be placed into the soil. The soil temperature is an important variable in accurate EDG testing.

5. Calibration Check Unit

6. Soil Darts

To get electrical data from the soil, 4 Soil Darts are pounded into the ground by a hammer. A template is provided to accurately position the Soil Darts.

The Soil Darts are machined by stainless steel and are expected to last many years.

7. Battery Charger

The Battery Charger that is provided with EDG will charge the battery in approximately 12 hours.

8. Hammer 9. Cables/Clips for Soil Measurement Sensor

10. Safety Glasses

11. Break-Out Cable

12. SR-4500 Manual

13. Software

14. EDG Testing Equipment Brochure

Soil Density Gauge - SR4500 Murah

Advantages of EDG

=> Non-Nuclear : This is the primary advantage. EDGs eliminate the need for radioactive sources, which means there are no concerns with radiation exposure, specialized licensing for operators, or strict regulations for shipping, handling, and storage. This also reduces overall costs and simplifies logistics.

=> Ease of Use : EDGs are generally considered easier to learn and operate than nuclear gauges. Their user-friendly, menu-driven interface guides the operator through the testing process.

=> Portability : They are lightweight, battery-powered, and easy to transport to job sites.

=> Accuracy : While early models had some issues, modern EDGs provide results that are highly comparable to traditional methods like the sand-cone and nuclear gauges and are repeatable. They are widely accepted for quality assurance and quality control (QA/QC) in construction projects.

EDGs are used in a variety of civil engineering and construction applications, including :

Road Construction : To check the compaction of sub-grade, sub-base, and aggregate base layers.

Foundation Work : To verify the density of compacted soil beneath foundations for buildings and other structures.

Utility Backfill : To ensure proper compaction of soil used to backfill trenches and excavations for utilities.
