Profometer PROCEQ

18 Maret 2020 • 20x dilihat

Profometer® 6 Cover Meters by Proceq are the sixth generation in over 40 years of quality instruments designed for determining location and measurement of concrete reinforcing steel. These models offer greater flexibility, productivity and advanced technology than ever, with high-resolution color touchscreen operation, internal 8GB flash memory, dual-core processors and instant model upgrades through purchase of an activation key.

Profometer PROCEQ

Profometer 650 AI offers the full reporting features of the CT-163, and adds Proceq’s unique Cross-Line Scan measuring mode and analysis functions. The 2D Cross-Line Scan feature provides the ability to combine linear scans in the X and Y axis into a single representation of first and second layers of reinforcing bars. Details of cover, bar diameter and signal strength are all displayed. Adjustments to signal strength gain and offset can be made to define specific features, such as allowing display of only the first layer of rebars.

Features:

Color display with touchscreen operation

Measurement range and detection up to 7.3in (185mm) deep

Cover accuracy of ±0.16in (4mm)

Rugged construction optimized for field use

ProfometerLink software for downloading of data and customized reports

Easy model upgrades through purchase of Activation Keys

Cover Meter models easily convert to Corrosion Meters with optional CTA-91 kit and desired Corrosion Electrode

Click Here : PROCEQ Profometer Catalog

Click Here : PROCEQ Pundit Live Array Pro Brochure

Click Here : PT. Mora Anugerah Berkat Telah Terdaftar di E-Catalog LKPP

Accessories:

CTA-81 Upgrade Kit, (CT-160 to CT-163) with Activation Key that can be purchased to upgrade to CT-163 features

CTA-82 Upgrade Kit, (CT-163 to CT-165) purchased separately with Activation Key to upgrade to features of CT-165

CTA-85 Telescopic Extension Rod w/Cable makes collecting data from overhead or at floor level easier

CTA-91 Conversion Kit for converting Profometer Cover Meters to CT-170 Profometer Corrosion Meter; Corrosion Electrode probe purchased separately

Specification	Profometer
Cover Measuring Range	Up to 7in (185mm)
Cover Measuring Accuracy	± 0.04 - 0.16in (1 - 4mm), depending on cover
Diameter Measuring Range	Up to 2.5in (63mm)
Diameter Measuring Accuracy	±1 rebar size
Power Supply	3.6V Internal Battery
Memory Capacity	8GB Internal Flash Memory
Product Dimensions	9.8 x 6.4 x 2.4 in (250 x 162 x 62 mm) WxDxH
Estimated Shipping Weight	16.0 lb (7.26 kg)

===========================================================

Profometer PROCEQ

===========================================================

MODEL

Profometer 650 AI | Profometer 630 AI

Description

Advanced cover meter based on the new generation Profometer touchscreen with universal probe and scan cart.Enhanced correction factor for maximum cover accuracy on congested rebar arrangements. Dedicated functionalities for mapping concrete cover and for reporting any 2D rectangular rebar arrangement.

Advanced cover meter based on the new generation Profometer touchscreen with universal probe and scan cart. Enhanced correction factor for maximum cover accuracy on congested rebar arrangements. Dedicated functionalities for mapping concrete cover and for reporting one layer rebar arrangements.

Benefit

Highest cover measurement accuracy ever through Artificial Intelligence (AI) feature

Full 2D rebar visualization with detailed cover, rebar size and spacing data for fast reporting

Advanced statistical tools to evaluate concrete cover compliance to specified minimum values

Scalable solution with upgrade possibility to Profometer Corrosion

Scalable solution with upgrade possibilities to Profometer 650 AI and Profometer Corrosion

Click Here : PROCEQ Profometer Catalogue

Click Here : PROCEQ Pundit Live Array Pro Brochure

Click Here : PT. Mora Anugerah Berkat Telah Terdaftar di E-Catalog LKPP

Cover Measuring Range

Up to 185 mm

Cover Measuring Accuracy

± 1 to 4 mm, depending on cover

Path Measuring Accuracy On Smooth Surface

0.5 to 1.0 % of measured length

Diameter Measuring Range

Up to 63 mm

Diameter Measuring Accuracy

± 1 rebar size

Available Upgrades

To Profometer Corrosion

To Profometer 650 AI

To Profometer Corrosion

===========================================================

Profometer PROCEQ

===========================================================

MODEL

Profometer 600 | Profoscope (+)

Description

Advanced cover meter based on the new generation Profometer touchscreen allowing full data review directly on the instrument. Lightweight IP 67 universal probe with detachable scan cart and spot functionality for measurements where space is limited.

Handy cover meter with integrated display and assisted detection feature. Profoscope+ includes all Profoscope features plus internal memory available for storing measured covers and diameters.

Benefit

Scalable solution with upgrade possibilities to Profometer 630 AI/650 AI and Profometer Corrosion

Designed for single handed operation

Profometer entry level model

Intuitive icon-based interface for fast operation

Ruggadized scan cart allows measurements on rough surfaces with optional extension rod

Rugged water-proof construction

Cover Measuring Range

Up to 185 mm

Cover Measuring Accuracy

± 1 to 4 mm, depending on cover

Path Measuring Accuracy On Smooth Surface

0.5 to 1.0 % of measured length

Diameter Measuring Range

Up to 63 mm

Diameter Measuring Accuracy

± 1 rebar size

Available Upgrades

To Profometer 630 AI/650 AI

From Profoscope to Profoscope+

To Profometer Corrosion

Click Here : PROCEQ Profometer Catalogue

Click Here : PROCEQ Pundit Live Array Pro Brochure

Click Here : PT. Mora Anugerah Berkat Telah Terdaftar di E-Catalog LKPP

Instrument Firmware

2-Layer Neighboring Rebar Correction Artificial Intelligence (NRC AI)

Cover calibration

Zoom in to scale rebars according to your needs

Display with cover curve or signal strength curve

Signal strength spectrum for further evaluation

Visual assistance for scanning speed and signal strength control

Settings directly accessible on the measurement screen

Graphical display of measured values and minimum cover set

Change settings before and after storage

11 Languages and timezone supported

Instrument Firmware

1-Layer Neighboring Rebar Correction (NRC)

Visual assistance for scanning speed and signal strength control

Real-time visualization of the rebars beneath the instrument

Settings directly accessible on the measurement screen

Visual indication of rebars in close proximity

Graphical display of measured values and minimum cover set

Identify the mid-point between rebars as well as the orientation of rebars

Optical and acoustical indication of rebar location and minimum cover alert

Change settings before and after storage

Neighboring bar correction

Switchable display backlight for dark environments

11 Languages and timezone supported

Start-up test kit allows user to familiarize on all functions in a comfortable environment, wasting no time on site

Language independent
